SY16345CDFD

Production
36V, 300mA LDO
Datasheet
SY16345CDFD 36V, 300mA LDO Datasheet
Part number SY16345CDFD
Vin (max) (V) 36
Vin (min) (V) 4
Iout (max) (A) 0.3
Output type Adjustable
Vout (max) (V) 36
Vout (min) (V) 0.6
Iq (typ) (uA) 10
PSRR at 100kHz (dB) 30
Accuracy (±%) 2
Features Enable,Fixed soft-start,Auto-discharge,Low Iq,Over current protection,Thermal shutdown
Operating temperature range(°C)
Package DFN2×2-8
Functional safety category
  • Wide Input Voltage Range: 4V to 36V
  • 300mA Maximum Load Current
  • Low Dropout Voltage of (300mV @ 300mA)
  • Low Quiescent Current (10µA typ.)
  • Low Shutdown Current (2µA typ.)
  • Stability with Tantalum or Ceramic capacitors
  • Excellent Load and Line Regulation
  • Enable Control Input
  • Over Current Protection
  • Thermal Shutdown
  • Package: DFN2×2-8
  • Automotive AEC- Q100 Grade 1 Qualified

The SY16345CDFD is an efficient, precise LDO designed for high input voltage and ultra-ow quiescent current applications.

The SY16345CDFD provides adjustable output voltage and very low drop out (300mV at 300mA). Other features include the operation stability with low ESR ceramic or tantalum capacitors due to the optimized internal compensation, over current protection and thermal shutdown.

The SY16345CDFD is available in DFN2×2-8 package.
