High Efficiency 5.5V, 3A continuous, 1MHz Synchronous Step Down Regulator
![]()
- Parameters
- Features
- Description
| Part Number | SY20113FDFC |
|---|
| Vin_min (V) | 2.7 |
|---|
| Vin_max (V) | 5.5 |
|---|
| Io_max (A) | 3 |
|---|
| Channels | |
|---|
| Vo_min (V) | 0.6 |
|---|
| Fsw (MHz) | 1 |
|---|
| Vref (V) | |
|---|
| Vref Accuracy | ±1.5% |
|---|
| Iq (uA) | 55 |
|---|
| Rdson1 | 110 |
|---|
| Rdson2 | 80 |
|---|
| Soft Start | 1.2 |
|---|
| Package | DFN2x2-8 |
|---|
| Topology | |
|---|
| Protection Mode | Hic-cup SCP |
|---|
| Features / Special Function | Power Good Indicator,Auto-Discharge,100% Dropout Operation |
|---|
| Temp Range | |
|---|
- Low RDS(ON) for internal switches(top/bottom):110mΩ/80mΩ
- 3A continuous load current capability
- 2.7-5.5V input voltage range
- High switching frequency minimizes the external components: 1MHz
- Internal softstart limits the inrush current
- Reliable hic-cup short circuit protection:
- 100% dropout operation
- RoHS Compliant and Halogen Free
- Compact package: DFN2x2-8
The SY20113F is high-efficiency, high frequency synchronous step-down DC-DC regulator IC capable of delivering up to 3A output current. The SY20113F operates over a wide input voltage range from 2.7V to 5.5V and integrate main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss.
Low output voltage ripple and small external inductor and capacitor sizes are achieved with 1MHz switching frequency.
SY20113F integrates reliable short circuit and over-voltage protection.
