SY20418AAHC

Production
0.7V Minimum Input and Fixed Output 100mA Maximum Output Current Synchronous Boost
Datasheet
SY20418AAHC 0.7V Minimum Input and Fixed Output 100mA Maximum Output Current Synchronous Boost Datasheet
    Part NumberSY20418AAHC
    Vin_min (V)0.7
    Vin_max (V)5
    Limit Current (A)0.35
    Fsw (MHz)
    Vo_max (V)5.25
    Vref Accuracy±3%
    Rdson1400
    Rdson2500
    Features / Special FunctionFixed Vout, Bypass function @ shutdown
    PackageSOT-363



    • 0.7V Minimum Input Voltage
    • 7μA Typical Quiescent Current
    • Input Under-voltage Lockout
    • Pass-through Function During Shutdown
    • Low RDS(ON) (Main Switch/Synchronous Switch) at Output: 0.4/0.5Ω
    • Fixed 5V Output Voltage
    • Typical 350mA Peak Current Limit
    • Compact SOT-363(SC70) Package



    Evaluation Board

    • SY20418AAHC-a

      Photo of evaluation board

    • SY20418AAHC-b

      Photo of evaluation board

    • SY20418AAHC-c

      Photo of evaluation board

    EVB_SY20418AAHC

    The EVB_SY20418AAHC is intended for evaluating a high efficiency synchronous boost regulator SY20418A. It can receive an input voltage as low as 0.7V.
