SY20418AHC

Production
0.7V Minimum Input and 100mA Maximum Output Current Synchronous Boost
Datasheet
SY20418AHC 0.7V Minimum Input and 100mA Maximum Output Current Synchronous Boost Datasheet
    Part NumberSY20418AHC
    Vin_min (V)0.7
    Vin_max (V)5
    Limit Current (A)0.35
    Fsw (MHz)
    Vo_max (V)5.25
    Vref Accuracy±3%
    Rdson1500
    Rdson2700
    Features / Special FunctionPass-through function @ shutdown
    PackageSOT-363



    • 0.7V Minimum Input Voltage
    • 5 μA Typical Quiescent Current
    • Input Under Voltage Lockout
    • Pass-through Function During Shutdown
    • Low RDS(ON) (Main Switch/Synchronous Switch) at Output: 0.5/0.7Ω
    • Typical 350mA Peak Current Limit
    • RoHS Compliant and Halogen Free
    • Compact SOT-363(SC70) Package



    Evaluation Board

    • SY20418AHC-b

      Photo of evaluation board

    • SY20418AHC-c

      Photo of evaluation board

    • SY20418AHC-a

      Photo of evaluation board

    EVB_SY20418AHC

    The EVB_SY20418AHC is intended for evaluating a high efficiency synchronous boost regulator SY20418.  It can receive an input voltage as low as 0.7V.
