SY20466BQMC

Production
1.8V Minimum Input and 5. 5V Maximum Output 6A Peak Current Synchronous Boost with Output Disconnect
Datasheet
SY20466BQMC 1.8V Minimum Input and 5. 5V Maximum Output 6A Peak Current Synchronous Boost with Output Disconnect Datasheet
    Part NumberSY20466BQMC
    Vin_min (V)1.8
    Vin_max (V)5.25
    Limit Current (A)6
    Fsw (MHz)0.5
    Vo_max (V)5.5
    Vref Accuracy±1.5%
    Rdson120
    Rdson240
    Features / Special FunctionLow Battery Comparator, Disconnect @Shutdown
    PackageQFN2x2-10
    • 1.8V Minimum Input Voltage
    • Adjustable Output Voltage from 2.5V to 5. 5V
    • 6A Peak Current Limit
    • Input under Voltage Lockout
    • Load Disconnect during Shutdown
    • Selectable Forced PWM Mode Operation
    • Output Over Voltage Protection
    • Low RDS(ON) (Main Switch/Synchronous Switch) at 5.0V Output: 20/40mΩ
    • Compact package: QFN2x2-10

    Evaluation Board

    • SY20466BQMC-e

      Photo of evaluation board

    • SY20466BQMC-c

      Photo of evaluation board

    • SY20466BQMC-b

      Photo of evaluation board

    • SY20466BQMC-a

      Photo of evaluation board

    • SY20466BQMC-d

      Photo of evaluation board

    EVB_SY20466BQMC

    The EVB_SY20466BQMC is intended for evaluating a high efficiency synchronous boost regulator SY20466B. It can disconnect the output during the shutdown operation.
