SY20493SUC

Production
0.85V Minimum Input and 5. 5V Maximum Output High Efficiency 2A Valley Current Synchronous Boost
Datasheet
SY20493SUC 0.85V Minimum Input and 5. 5V Maximum Output High Efficiency 2A Valley Current Synchronous Boost Datasheet
    Part NumberSY20493SUC
    Vin_min (V)0.85
    Vin_max (V)5.5
    Limit Current (A)2
    Fsw (MHz)1
    Vo_max (V)5.5
    Vref Accuracy±1.5%
    Rdson170
    Rdson2125
    Features / Special FunctionAuto Bypass Mode When VIN ≥VOUT; OVP
    PackageDFN2x1.5-6



    • 0.85V Minimum Input Voltage
    • Adjustable Output Voltage From 1.8V to 5.5V
    • Min 2A Valley Current Limit
    • 5µA Typical Quiescent Current
    • Load Disconnect During Shutdown
    • Low RDS(ON) (Main Switch/Synchronous Switch) at 3.3V Output: 70/125mΩ
    • Output OVP
    • RoHS Compliant and Halogen Free
    • Auto Bypass Mode When VIN ≥VOUT
    • Compact Package DFN2x1.5-6



    Evaluation Board

    • SY20493SUC-a

      Photo of evaluation board

    • SY20493SUC-c

      Photo of evaluation board

    • SY20493SUC-b

      Photo of evaluation board

    EVB_ SY20493SUC_1

    The EVB_ SY20493SUC_1 is intended for evaluating a high efficiency, synchronous, step-up Boost converter SY20493. It can disconnect the output from the input during the shutdown mode. When input voltage exceeds the regulated output voltage, SY20493 enters bypass mode automatically.
