The SY70301 is a high efficiency, quad-output, synchronous buck regulator that operates over a wide input voltage range of 2.5V to 5.5V. It features a total of four integrated power stages: two that can deliver continuous output current of up to 6A, and two that can deliver continuous output current of up to 4A. This flexibility allows the device to work for a wide range of applications that require high power and multiple outputs.

The SY70301 uses constant on-time (COT) and instant PWM control scheme to achieve fast transient response and loop stabilization. Seamless DCM/CCM transitions maximize efficiency at either heavy or light load. During startup and voltage changes, the device controls the output slew rate to minimize output voltage overshoot and inrush current.

The SY70301 supplies undervoltage lockout (UVLO) along with overvoltage (OVP), overcurrent (OCP), and overtemperature (OTP), protection to ensure reliable system operation.

In addition to the standard interrupt and chip enable, the SY70301 also supports I2C communication protocol.

The SY70301 is available in a QFN4.5mm×5mm-30 package.
